Data handling

Quartiles and box-and-whisker

Five-number summary. Compare two classes with a box plot. Interquartile range.

CAPS

Grade 11 · Mathematical Literacy · Data handling

Mathematical Literacy uses a context, not a bare sum.

  • Two papers

    Paper 1 uses familiar contexts: pay slips, till slips, maps you have seen, and data in a table. Paper 2 uses less familiar contexts and expects you to decide which method fits. Both papers are 150 marks.

  • What to show

    Write the value with its unit or its rand sign. Say whether you multiply or divide, and round only at the end, in the way the question asked (nearest rand, one decimal place, a whole number of tiles).

  • The relation

    IQR=Q₃−Q₁. Interquartile range

  • How a marker reads it

    IQR is not the range. Range is max − min. Do not mix them.

A correct number with the wrong unit, or a VAT amount treated as the full price, loses the mark the context was testing.

Diagram

Quartiles and box-and-whisker

Worked example

Q₁=40, Q₃=70. IQR?

Before any working — hunt first

Given

Numbers and units already in the sentence: 40 · 70. Copy each one into a column. A name without a number is not given.

Missing

After you copy the given, the letter that still has no number is missing. The paper is pointing at: IQR. Circle that word — that is the missing variable.

Find

We are required to find: IQR. Write that as a symbol on the left, with a question mark, before you touch a formula.

Calculate

Write IQR = Q₃ − Q₁ with empty letters. Cross out every letter that already has a number. Calculate the letter that is still standing — that gives IQR.

Simplified approach

Subtract the lower quartile from the upper.

Culture note

Comparing two Grade 11 classes after a June test is the box-plot question.

Formulas

IQR=Q₃−Q₁

Interquartile range

Exam tricks you must know

These are the moves markers look for — not shortcuts that skip the method, but the habits that earn the method mark.

  • If the price already includes VAT, divide by 1.15 — do not subtract 15%

    How:Total = price × 1.15 when VAT is still to be added. When the till already shows VAT, price excluding = total1.15. Subtracting 15% of the total is a different number and loses the mark.

    When to use it:Till slips, VAT, and SARS-style tax questions.

  • Fencing is perimeter. Grass, paint and tiles are area. Tanks are volume.

    How:Underline the object: wire, border, fence → add the sides. Floor, wall, field, paint → multiply length by width, then divide by coverage and round tins up. Water in a tank → m³ then × 1 000 for litres.

    When to use it:Measurement papers: school fields, paint, Jojo tanks.

  • Always substitute the usage into both tariff options — the cheaper one can swap after break-even

    How:Write cost A and cost B as two lines. Set them equal if they ask where the deals match. Circle the smaller total at the given usage. A graph with two lines makes the swap obvious.

    When to use it:Cellphone contracts, prepaid electricity, and cake-sale break-even.

Step 1 / 5

Write the formula

IQR=Q₃−Q₁.

Diagram
Diagram
IQR=70−40=30

Why this step: We only do one job per line so a marker can follow the marks — and so you can find a slip without starting over.

More worked examples

Board walkthroughs on this topic. Open one, copy the working, then try the next.

Example 1 / 20

The ordered data has 8 values: 1, 2, 3, 4, 5, 6, 7, 8. Find Q1, Q3 and the interquartile range.

4. Step-by-step working

  1. 01

    Count the outcomes

    Lower half: 1, 2, 3, 4. Q1=(2 + 3)2=2.50.

    Q1=2.50
  2. 02

    Count the outcomes

    Upper half: 5, 6, 7, 8. Q3=(6 + 7)2=6.50.

    Q3=6.50
  3. 03

    Subtract

    IQR=6.50−2.50=4.

    4

How we got there

Read this like a teacher at the board. We go slowly, name every number, and say why we take each step.

Explain in another language · 11

1. What is the question asking?

Read the question twice. Circle the unknown. Underline every number and unit. The paper is asking: The ordered data has 8 values: 1, 2, 3, 4, 5, 6, 7, 8. Find Q1, Q3 and the interquartile range.

Before any working — hunt first

Given

Numbers and units already in the sentence: 8 values · 1 · 2 · 3 · 4 · 5 · 6 · 7 · 8 · 1 · 3 and. Copy each one into a column. A name without a number is not given.

Missing

After you copy the given, the letter that still has no number is missing. The paper is pointing at: Q1, Q3 and the interquartile range. Circle that word — that is the missing variable.

Find

We are required to find: Q1, Q3 and the interquartile range. Write that as a symbol on the left, with a question mark, before you touch a formula.

Calculate

Write Q1 = 2.50 with empty letters. Cross out every letter that already has a number. Calculate the letter that is still standing — that gives Q1, Q3 and the interquartile range.

In other words — as if you have never seen this before

If you have never seen this before: With an even number of values there is no single middle. Q1 is the median of the lower half. Q3 is the median of the upper half. IQR = Q3 − Q1. We will name a method in words, write the formula with no numbers, then substitute one line at a time.

2. What do we already know?

Eight ordered numbers. Split into a lower four and an upper four.

3. Which method — and why this one?

With an even number of values there is no single middle. Q1 is the median of the lower half. Q3 is the median of the upper half. IQR = Q3 − Q1.

4. Step-by-step working

  1. 01 / 06

    Count the outcomes

    Lower half: 1, 2, 3, 4. Q1=(2 + 3)2=2.50.

    Q1=2.50

    Why this step: We only do one job per line so a marker can follow the marks — and so you can find a slip without starting over.

  2. 02 / 06

    Count the outcomes

    Upper half: 5, 6, 7, 8. Q3=(6 + 7)2=6.50.

    Q3=6.50

    Why this step: We only do one job per line so a marker can follow the marks — and so you can find a slip without starting over.

  3. 03 / 06

    Subtract

    IQR=6.50−2.50=4.

    4

    Why this step: We only do one job per line so a marker can follow the marks — and so you can find a slip without starting over.

  4. 04 / 06

    Step G — Sense-check the size

    Ask: is this the kind of number a Grade 10–12 paper would want? A speed of 3 000 ms for a learner walking, or a probability bigger than 1, means a unit or algebra slip. Estimate first: round the numbers and do the sum in your head.

    Why this step: Markers write ‘unrealistic’ in the margin when the method is right but the size is wild. A 10-second head check often finds a missing 10² or a unit that never changed.

  5. 05 / 06

    Step F — Box the answer with its unit

    Q1=2.50, Q3=6.50, IQR=4.

    Why this step: A number without a unit is half a mark on a Physics paper, and a marker can miss a Maths answer that is buried in working.

  6. 06 / 06

    Step H — What the marker is looking for

    On an NSC memo you usually earn: (1) a method mark for naming the right formula or idea in words, (2) an accuracy mark for substituting the given numbers with units, (3) an accuracy mark for the boxed answer with its unit. Write those three lines even if you are unsure of the arithmetic — blank pages score zero.

    Why this step: First-timers chase the final number and leave the method blank. The memo still pays out for the idea and the substitution even when the last line is wrong.

5. The answer

Q1=2.50, Q3=6.50, IQR=4.

Copy onto your answer sheet — in this order

Formula: Q1=2.50

Answer: Q1=2.50, Q3=6.50, IQR=4.

6. Check it like a marker

The range is the biggest minus the smallest. The interquartile range ignores that pair and uses Q3 and Q1.

7. A trap first-timers fall into

First-timers often grab the first formula they remember, mix units (cm with m, minutes with seconds), or drop a minus sign. Write the formula in words first: “this equals that, because…”
